For example:Īre two rnicrooperations that specify a 1-bit shift to the left of the content of register R 1 and a 1-bit shift to the right of the content of register R2. We will adopt the symbols shl and shr for logical shift-left and shift-right rnicrooperations.
BASIC DATA MOVEMENT IN SHIFT REGISTERS SERIAL
Logical shift: A logical shift is one that transfers 0 through the serial input. There are three types of shifts: logical, circular, and arithmetic. The information transferred through the serial input determines the type of shift. During a shift-right operation the serial input transfers a bit into the leftmost position. During a shift-left operation the serial input transfers a bit into the rightmost position. At the same time that the bits are shifted, the first flip-flop receives its binary information from the serial input. The contents of a register can be shifted to the left or the right. They are also used in conjunction with arithmetic, logic, and other data-processing operations. Shift rnicrooperations are used for serial transfer of data.
